VKMZ200 ventilators Ø 200 mm

Apraksts

VKMZ200 ventilators Ø 200 mm, augstspiediena, metāla

Current: 0.69
Duct diameter: 200
Max. transported air temperature: -25 +45
Low-powered motor Low-powered motor: no
Design: centrifugal
Voltage: 1~ 220-240
Frequency: 50
Sound pressure level at 3 m distance: 50
Casing material: galvanized steel
Power consumption: 157
Maximum air capacity: 1000
RPM: 2740
Protection rating: IP X4
Weight: 5.43
SEC Class: C
Outdoor mounting: yes
Form-ducts: for round air ducts
Type:
Mounting: outdoor mounting, wall mounting, Inline
