VKMZ315 ventilators Ø 315 mm

Apraksts

VKMZ315 ventilators Ø 315 mm, augstspiediena, metāla

Current: 0.81
Duct diameter: 315
Max. transported air temperature: -25 +45
Low-powered motor Low-powered motor: no
Design: centrifugal
Voltage: 1~ 220-240
Frequency: 50
Sound pressure level at 3 m distance: 53
Casing material: galvanized steel
Power consumption: 185
Maximum air capacity: 1540
RPM: 2730
Protection rating: IP X4
Weight: 6.57
SEC Class: C
Outdoor mounting: yes
Form-ducts: for round air ducts
Type:
Mounting: outdoor mounting, wall mounting, Inline
